S110 Series
LED Street Light

S110 Series LED Street Light

  • Cree/ Osram/ Philips-Lumileds and Samsung led chips options, flip chip technology, single unit’s damage won’t affect others’ normal work;
  • Easy to change the driver and led modules; class I, class II driver with dimmer optional, 0-10v, PWM, Dali
  • Designed to last at least 100,000 hours at L80;
  • Multiple lighting distributions available, fit for different road and standard;
  • Standard color temperatures: 3000K, 4000K, 6500K; minimum 80 CRI
  • IK09 and IP67 modules: highest waterproof level, hot-pluggable, easy for installation and replacement;
  • Multiple housing colors: black, white, grey;
  • CE,CB,ENEC Certification;
  • Photocell led road luminaires,tool-free led street lamp;
  • Adjustable angle design;
  • Power automactically switch off when opening
  • 6-year limited warranty;

Color Options

Color Option

Application

Municipal road, street, Public Park, parking lot,urban lights,Highway roads etc.

Technical Characteristics

Model No.PowerEfficacyLumen OutputCCTIP IKLed SourceDriverLifespan
LS-S110S-100100W130LM/W13000LM3000K-6500KIP66,IK08Philips/CreeMeanwell/Inventroincs/Epistar/Bridgelux/Custom Brand6 years
LS-S110M-200200W130LM/W26000LM3000K-6500KIP66,IK08Philips/CreeMeanwell/Inventroincs/Epistar/Bridgelux/Custom Brand6 years
LS-S110L-300300W130LM/W39000LM3000K-6500KIP66,IK08Philips/CreeMeanwell/Inventroincs/Epistar/Bridgelux/Custom Brand6 years
